Installing side grip (auxiliary handle)
The side grip is an important means of maintaining good control of this hammer drill
during use in the even bit or accessory jams, causing the tool twist from your hand with
the potential t o cause injury. Loosen the wing nut on the side grip and install the side grip
on the tool. The side grip swings around t o either side, allowing easy handling of the tool
in any position. Swing the side grip t o the desired position and then tighten the wing nut
t o secure the side grip.
Installing or removing drill bit
CAUTION :
Always be sure that the tool i s switched off and unplugged before installing or removing
the bit.
To install the bit, place it in the chuck as
far as it will go. Tighten the chuck by hand.
Place the chuck key in each of the three
holes and tighten clockwise. Be sure t o
tighten all three chuck holes evenly.
To remove the bit, turn the chuck key
counterclockwise in just one hole, then
loosen the chuck by hand.
After using the chuck key, be sure to return it t o the original position.
Depth gauge
The depth gauge i s convenient for drilling
holes of uniform depth. Loosen the wing
bolt and adjust the depth gauge to the desired depth. After adjusting, tighten the
wing bolt t o secure the depth gauge.
5
