IP Link® Device Interface
Communication Sheet
vvtk_1_7342_1.pke
Revision: 5/27/2014
This document provides additional assistance with wiring your Extron IP Link enabled product to your device.
Different components may require a different wiring scheme than those listed below.
For complete operating instructions, refer to the user's manual for the specific Extron IP Link enabled product or
the controlled device manufacturer supplied documentation.
Device Specifications:
Device Type:
Manufacturer:
Firmware Version:
Model(s):
Video Projector
Vivitek
N/A
D5010-WNL
Version History:
Driver
Version
1
Date
5/20/2014
IP Link
Compiler
GC
Version
1.6.0
3.5.2
Notes
Initial version.
Driver Notes:
 Driver has been optimized for Volume.
 Device ID is set to default of 1.
 When Device ID is set to Broadcast, status is not supported.
Page 1 of 5
IP Link® Device Interface
Communication Sheet
vvtk_1_7342_1.pke
Revision: 5/27/2014
Control Commands & States:
Aspect Ratio
Fill
4:3
16:9
Letterbox
Native
2.35:1
Auto Image
Execute
Device ID
Broadcast
0 to 98
Freeze
On
Off
Input
RGB 1
RGB 2
DVI
Video
S-Video
HDMI1
HDMI2
BNC
Component
Display Port
Multimedia
Up
Down
Left
Right
Enter
Menu
Power Control
On
Off
Video Mute
On
Off
Volume (Discrete)
0 to 10 in steps of 1
Volume (Step)
Up
Menu Navigation
Down
Page 2 of 5
IP Link® Device Interface
Communication Sheet
vvtk_1_7342_1.pke
Revision: 5/27/2014
Status Available:
Fill
4:3
16:9
Letterbox
Native
2.35:1
Connection Status
Connected
Disconnected
Status Unavailable
Freeze
On
Off
Input
RGB 1
RGB 2
DVI
Video
S-Video
HDMI1
HDMI2
BNC
Component
Display Port
Multimedia
Aspect Ratio
Lamp Usage
Hours
Power Control
On
Off
Power Status
On
Off
Status Unavailable
Video Mute
On
Volume (Discrete)
0 to 10 in steps of 1
Off
Page 3 of 5
Cooling Down
IP Link® Device Interface
Communication Sheet
vvtk_1_7342_1.pke
Revision: 5/27/2014
MLC60 Series Supported Commands:*
Aspect Ratio
Fill
4:3
16:9
Letterbox
Native
2.35:1
Auto Image
Execute
Freeze
On
Off
Input
RGB 1
RGB 2
DVI
Video
S-Video
HDMI1
HDMI2
BNC
Component
Display Port
Multimedia
Up
Down
Left
Right
Enter
Menu
Power Control
On
Off
Video Mute
On
Off
Volume (Discrete)
0 to 10 in steps of 1
Volume (Step)
Up
Menu Navigation
Down
*Device ID is set to default of Broadcast for MLC 60 Series.
Page 4 of 5
vvtk_1_7342_1.pke
IP Link® Device Interface
Communication Sheet
Revision: 5/27/2014
Cable and Adapter Requirements:
M/F DB9 RS232 Null Modem Cable
Notes for the Device:
Serial communication:
Port Type: RS-232
Baud Rate: 9600
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control: None
Pin Assignments Diagram:
Note: Captive screw connector may also be used as a serial connection.
General Notes:
